STM32L432KCU6 tekniska specifikationer
STMicroelectronics - STM32L432KCU6 Tekniska specifikationer, attribut, parametrar och delar med liknande specifikationer som STMicroelectronics - STM32L432KCU6
| Produktattribut | Attributvärde | |
|---|---|---|
| Tillverkare | STMicroelectronics | |
| Spänning - Tillförsel (Vcc / Vdd) | 1.71V ~ 3.6V | |
| Leverantörs Device Package | 32-UFQFPN (5x5) | |
| Fart | 80MHz | |
| Serier | STM32L4 | |
| RAM-storlek | 64K x 8 | |
| Programminne Typ | FLASH | |
| Programminnesstorlek | 256KB (256K x 8) | |
| kringutrustning | Brown-out Detect/Reset, DMA, PWM, WDT | |
| Förpackning / Fodral | 32-UFQFN Exposed Pad | |
| Paket | Tray |
| Produktattribut | Attributvärde | |
|---|---|---|
| Oscillatortyp | Internal | |
| Driftstemperatur | -40°C ~ 85°C (TA) | |
| Antal I / O | 26 | |
| Monteringstyp | Surface Mount | |
| EEPROM-storlek | - | |
| Datakonverterare | A/D 10x12b; D/A 2x12b | |
| Kärnstorlek | 32-Bit Single-Core | |
| Core Processor | ARM® Cortex®-M4 | |
| Anslutningar | CANbus, I²C, IrDA, LINbus, QSPI, SAI, SPI, SWPMI, UART/USART, USB | |
| Basproduktnummer | STM32L432 |
De tre delarna till höger har liknande specifikationer som STMicroelectronics STM32L432KCU6.
| Produktattribut |  |
 |
|
 |
|---|---|---|---|---|
| Artikelnummer | STM32L432KCU6 | STM32L433CCU3 | STM32L433CCU3TR | STM32L433CBT6 |
| Tillverkare | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| Monteringstyp | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| EEPROM-storlek | - | - | - | - |
| Leverantörs Device Package | 32-UFQFPN (5x5) | 48-UFQFPN (7x7) | 48-UFQFPN (7x7) | 48-LQFP (7x7) |
| Förpackning / Fodral | 32-UFQFN Exposed Pad | 48-UFQFN Exposed Pad | 48-UFQFN Exposed Pad | 48-LQFP |
| Antal I / O | 26 | 38 | 38 | 38 |
| Paket | Tray | Tray | Tape & Reel (TR) | Tray |
| Driftstemperatur | -40°C ~ 85°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 85°C (TA) |
| Oscillatortyp | Internal | Internal | Internal | Internal |
| RAM-storlek | 64K x 8 | 64K x 8 | 64K x 8 | 64K x 8 |
| Programminnesstorlek | 256KB (256K x 8) | 256KB (256K x 8) | 256KB (256K x 8) | 128KB (128K x 8) |
| Core Processor | ARM® Cortex®-M4 | ARM® Cortex®-M4 | ARM® Cortex®-M4 | ARM® Cortex®-M4 |
| Anslutningar | CANbus, I²C, IrDA, LINbus, QSPI, SAI, SPI, SWPMI, UART/USART, USB | CANbus, I²C, IrDA, LINbus, MMC/SD, QSPI, SAI, SPI, SWPMI, UART/USART, USB | CANbus, I²C, IrDA, LINbus, MMC/SD, QSPI, SAI, SPI, SWPMI, UART/USART, USB | CANbus, I²C, IrDA, LINbus, MMC/SD, QSPI, SAI, SPI, SWPMI, UART/USART, USB |
| Spänning - Tillförsel (Vcc / Vdd) | 1.71V ~ 3.6V | 1.71V ~ 3.6V | 1.71V ~ 3.6V | 1.71V ~ 3.6V |
| Datakonverterare | A/D 10x12b; D/A 2x12b | A/D 10x12b; D/A 2x12b | A/D 10x12b; D/A 2x12b | A/D 10x12b; D/A 2x12b |
| Serier | STM32L4 | STM32L4 | STM32L4 | STM32L4 |
| Kärnstorlek | 32-Bit Single-Core | 32-Bit Single-Core | 32-Bit Single-Core | 32-Bit Single-Core |
| Basproduktnummer | STM32L432 | STM32L433 | STM32L433 | STM32L433 |
| Programminne Typ | FLASH | FLASH | FLASH | FLASH |
| Fart | 80MHz | 80MHz | 80MHz | 80MHz |
| kringutrustning | Brown-out Detect/Reset, DMA, PWM, WDT | Brown-out Detect/Reset, DMA, LCD, PWM, WDT | Brown-out Detect/Reset, DMA, LCD, PWM, WDT | Brown-out Detect/Reset, DMA, LCD, PWM, WDT |
Ladda ner STM32L432KCU6 PDF -datablad och STMicroelectronics -dokumentation för STM32L432KCU6 - STMicroelectronics.
