ACT412US-T tekniska specifikationer
Active-Semi - ACT412US-T Tekniska specifikationer, attribut, parametrar och delar med liknande specifikationer som Active-Semi - ACT412US-T
| Produktattribut | Attributvärde | |
|---|---|---|
| Tillverkare | Active-Semi | |
| Spänning - Tillförsel (Vcc / Vdd) | 5.4 V ~ 22 V | |
| Spänning - Starta upp | 12.35V | |
| Spänning - Uppdelning | - | |
| Topologi | Flyback | |
| Leverantörs Device Package | SOT-23-6 | |
| Serier | ActivePSR™, ActiveQR™ | |
| Effekt (Watt) | 36W | |
| Förpackning | Tape & Reel (TR) | |
| Förpackning / Fodral | SOT-23-6 | |
| Utgångsisolering | Isolated |
| Produktattribut | Attributvärde | |
|---|---|---|
| Andra namn | 1488-1051-2 ACT412US-T-ND |
|
| Driftstemperatur | -40°C ~ 85°C (TA) | |
| Monteringstyp | Surface Mount | |
| Fuktkänslighetsnivå (MSL) | 1 (Unlimited) | |
| Ledningsfri status / RoHS-status | Lead free / RoHS Compliant | |
| Intern strömbrytare | No | |
| Frekvensomkoppling | Up to 120kHz | |
| Felskydd | Current Limiting, Over Temperature, Over Voltage, Short Circuit | |
| Driftscykel | 75% | |
| detaljerad beskrivning | Converter Offline Flyback Topology Up to 120kHz SOT-23-6 | |
| Kontrollfunktioner | - |
De tre delarna till höger har liknande specifikationer som Active-Semi ACT412US-T.
| Produktattribut |  |
|
|
|
|---|---|---|---|---|
| Artikelnummer | ACT412US-T | ACT410US-T | ACT413US-T | ACT413AUS-T |
| Tillverkare | Active-Semi | Active-Semi | Active-Semi | Active-Semi |
| Spänning - Tillförsel (Vcc / Vdd) | 5.4 V ~ 22 V | 6.8 V ~ 22 V | 6.8 V ~ 22 V | 6.8 V ~ 22 V |
| Kontrollfunktioner | - | - | - | - |
| Driftscykel | 75% | 75% | 75% | 75% |
| Fuktkänslighetsnivå (MSL) | 1 (Unlimited) | 1 (Unlimited) | 1 (Unlimited) | 1 (Unlimited) |
| Leverantörs Device Package | SOT-23-6 | SOT-23-6 | SOT-23-6 | SOT-23-6 |
| detaljerad beskrivning | Converter Offline Flyback Topology Up to 120kHz SOT-23-6 | Converter Offline Flyback Topology Up to 120kHz SOT-23-6 | Converter Offline Flyback Topology Up to 85kHz SOT-23-6 | Converter Offline Flyback Topology Up to 85kHz SOT-23-6 |
| Spänning - Starta upp | 12.35V | 12.35V | 12.35V | 12.35V |
| Monteringstyp | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Spänning - Uppdelning | - | - | - | - |
| Serier | ActivePSR™, ActiveQR™ | ActivePSR™ | ActivePSR™, ActiveQR™ | ActivePSR™, ActiveQR™ |
| Ledningsfri status / RoHS-status | Lead free / RoHS Compliant | Lead free / RoHS Compliant | Lead free / RoHS Compliant | Lead free / RoHS Compliant |
| Förpackning | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
| Felskydd | Current Limiting, Over Temperature, Over Voltage, Short Circuit | Current Limiting, Over Load, Over Temperature, Over Voltage, Short Circuit | Current Limiting, Over Load, Over Temperature, Over Voltage, Short Circuit | Current Limiting, Over Load, Over Temperature, Over Voltage, Short Circuit |
| Frekvensomkoppling | Up to 120kHz | Up to 120kHz | Up to 85kHz | Up to 85kHz |
| Utgångsisolering | Isolated | Isolated | Isolated | Isolated |
| Intern strömbrytare | No | No | No | No |
| Topologi | Flyback | Flyback | Flyback | Flyback |
| Driftstemperatur | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) |
| Förpackning / Fodral | SOT-23-6 | SOT-23-6 | SOT-23-6 | SOT-23-6 |
| Andra namn | 1488-1051-2 ACT412US-T-ND |
1488-1050-2 ACT410US-T-ND |
1488-1026-2 | - |
| Effekt (Watt) | 36W | 36W | 36W | 36W |
